HORUS DA8P Module (Premium)

Name: HORUS DA8P Module (Premium)
Brand: Merging
SKU: IOM-H-DA8P
Price: 810768 HUF
Availability: InStock

HORUS DA8P Module (Premium)

The DA8 (up to 192kz) and the DA8P (up to DSD) have consistently shown in testing to be the quietest multichannel D/A conversion modules available anywhere.

Main Benefits

123dB Signal to noise ratio (SNR)
Power up/power down auto-mutes (speaker protection)
Assignable Line up levels
Auto-mute circuitry for “no-pop” power cycling
Digitally controlled trims for line up procedures
Dynamic range of 127dB (typ.)
Easy to set dip switches for international operating levels

Description

Ravenna Technology

Using Ravenna technology, Horus brings to the table the possibility to interconnect your entire facility using nothing more than a standard RJ45 connector. Once in Ravenna mode, the Horus box simply becomes a node on a network, one that can be instantly called to be an input, an output, or a combination of both. Whether you are in broadcast, TV and film, CD/SACD mastering, studio or live music recording, live events, theatres, museums, cruise ships, or any industry where you need audio to get from A to B (or A to B and C, or C to A and part of D, E, and F!). Using standard network connections, switches and connectors, Horus and other Ravenna-enabled devices can be placed on a network and interconnected IN ANY WAY YOU CAN IMAGINE.

Features

• Up to 24 World Class Mic Preamps in a 2U chassis

• Remote controllable gain over Ethernet

• Integrated control and routing with the Pyramix Mixer interface

• 24 AD/DA converters capable of samplerates from 44.1 to 384kHz DXD/DSD

• Low Power "Green" build perfect for power conscious installations

• Auto-Mute circuitry for power cycling click prevention

• Comes standard with 1xMADI, 24xAES and Ravenna I/O

• Sync (LTC/MIDI/RS422) over Ethernet

• Front panel touch-screen interface for local control over routing/gains/sync

The Base Unit

The Horus Base unit comprises of everything you will ever need for a digital audio workflow. Add to that its Ravenna I/O connection and you have the perfect MassCore setup.

The Option Cards

Separate input and output cards allow you to customize your interface to exactly what you need for each application. Choose from standard, 192kHz capable or extended use DXD/DSD capable Inputs and outputs to make sure you capture every sound with the greatest accuracy.

AD8/AD8P Module

• 8 Mic/line inputs on DSUB with breakout XLR

• remote pre amp gain control over Ethernet

• Individual phantom power on all inputs

• Low power, Green design for low heat and low power consumption

• AD8: 44.1kHz – 192kHz

• AD8P:44.1kHz – 384kHz(DXD) and DSD

DA8/DA8P Module

• 123dB Signal to noise ratio (SNR)

• Power up/power down auto-mutes (speaker protection)

• Assignable Line up levels

Tech Specs

810 768 Ft (638 400 Ft nettó)

–

A kosárba helyezés gomb akkor jelenik meg, ha kiválasztotta a fenti értékeket

gyártó: Merging
termékkód: IOM-H-DA8P

Twitter

Recently viewed

QXS580-CCSI

QXS 580 boom pole, coiled cable installed, stereo XLR5 The QXS 580 Quickpole Light Boompole from Ambient Recording is a balanced boompole designed fo

QXS580-CCSI

A leírás megjelenítése a Tovább olvasás címkéig.: The QXS 580 Quickpole Light Boompole from Ambient Recording is a balanced boompole designed for engineering and video professionals. Built with five segments, the pole effectively delivers a better collapsed-to-extended ratio, enabling easy transportation while providing long lengths when needed.

Hívjon az árért

–

HW20913 - 16-ch Audio Interface selection for TM9 series

16-ch Audio Interface selection for TM9 series: 16-ch AES3 I/O (2 x Sub-D),Ethernet, VGA, 2 x USB 2.0, GPIO, 24 V DC connectors. One main unit shall

HW20913

A leírás megjelenítése a Tovább olvasás címkéig.: 16-ch AES3 I/O (2 x Sub-D),Ethernet, VGA, 2 x USB 2.0, GPIO, 24 V DC connectors. One main unit shall be ordered simultaneously: Order no.: 20900 + HW20913, or 20900OEM + HW20913.

Hívjon az árért

–

Overcovers Adv, White (Master Carton of 10 x Packs)

Rycote Overcovers Advanced, Wind Covers & Adhesive Mounts for Lavalier Mics (White) - 10 packs Product Code: 066312 The 10 packs of white Over

RYC066312

A leírás megjelenítése a Tovább olvasás címkéig.: The 10 packs of white Overcovers Advanced, Wind Covers & Adhesive Mounts for Lavalier Mics from Rycote include 50 pieces of 26mm fur discs and 250 pieces of 23mm round stickies.

63 792 Ft (50 230 Ft nettó)

–

DA8/DA8P Specifications
Max Line Output @ 0 dBFS (jumpers on +24 dBu)	+24 dBu +0/-0.5 dB
Frequency response +0/-0.3dB @ fs = 48000 Hz	6 Hz – 20 kHz
Frequency response +0/-0.3dB @ fs = 2.8224 MHz (DSD)	NA / 6 Hz – 20 kHz
Frequency response +0/-3.0dB @ fs = 2.8224 MHz (DSD)	NA / 2 Hz – 50 kHz
Line Output Impedance (Differential)	100 Ω
Dynamic Range (A-weighted, typ)	126 dB
THD+N D/A (1 kHz) @ 0 dBFS (IOM-HORUS-DA8)	< -113dB (0.00022 %)
THD+N D/A (1 kHz) @ 0 dBFS (IOM-HORUS-DA8P)	< -115dB (0.00018 %)
Interchannel Crosstalk @ 1kHz, typ.	-135 dB
Connector Pinout (DB-25 female)	AES59/Tascam Analog

Line Output Section
Max Output level software switchable for 0 dBFS	+24 dBu / +18 dBu +0/-0.5 dB
Frequency response +0/-0.3dB @ fs = 48 kHz	6 Hz – 22 kHz
Frequency response +0/-3dB @ fs = 96 kHz	6 Hz – 44 kHz
Frequency response +0/-3dB @ fs = 192 kHz	6 Hz – 88 kHz
Output Impedance (Differential)	< 100 Ω
Dynamic Range (A-weighted, typ.)	123 dB
THD+N (1 kHz) @ 0dBFS	< -108 dB (0.0004 %)
Interchannel Crosstalk @ 1kHz	< -135 dB
Connector Pinout	DB-25 / AES59 (Tascam Ana.)

Latencies
Input latency at 44.1/48kHz	16 samples
Input latency at 88.2/96kHz	16 samples
Input latency at 176.4/192kHz	13 samples
Output latency at 44.1/48kHz	9* samples
Output latency at 88.2/96kHz	9* samples
Output latency at 176.4/192kHz	9* samples

* Filter setting - Slow Roll Off Filter option = 9 Samples - Sharp Roll Off Filter option = 38 Samples
